dbSAFE MAX
SKU
dbSAFE MAX
Large size RF test enclosure, ≥100 dB isolation, 300 MHz - 18 GHz
Some applications require larger test environments. The dbSAFE MAX blends all the superior isolation characteristics of the standard dbSAFE DUO shielded box into a larger volume to guarantee you get better results.
SKU
dbSAFE MAX
Manufacturer
DVTEST
Shielding Effectiveness (dB)
300 MHz - 6 GHz ≥ 100 dB, 6 GHz - 18 GHz ≥ 90 dB
Chassis Type
Double Wall Welded Aluminium Structure
Surface Treatment
Tri-Shield© coated to MIL-DTL-5541F
Loading Style
Front
Base type
Extruded Aluminium Trolley
RF Gasket
Triple Layer Braid Over Foam
Absorber
High Performance, High Density 2.25” Pyramidal Absorber (Other absorber styles available, consult factory)
Internal Dimensions (WxDxH)
32" x 32" x 32"
External Dimensions (WxDxH)
39" x 39" x 39"
Warranty
3 Years
